A motherboard is the central or primary circuit board making up a complex electronic system, such as a modern computer. It is also known as a mainboard, baseboard, system board, or, on Apple computers, a logic board, and is sometimes abbreviated as mobo.^[1]

Most after-market motherboards produced today are designed for so-called IBM-compatible computers, which hold over 96% of the personal computer market today.^[2] Motherboards for IBM-compatible computers are specifically covered in the PC motherboard article.

The basic purpose of the motherboard, like a backplane, is to provide the electrical and logical connections by which the other components of the system communicate.

A typical desktop computer is built with the microprocessor, main memory, and other essential components on the motherboard. Other components such as external storage, controllers for video display and sound, and peripheral devices are typically attached to the motherboard via edge connectors and cables, although in modern computers it is increasingly common to integrate these "peripherals" into the motherboard.

[edit] Components and functions

The motherboard of a typical desktop consists of a large PCB. It holds electronic components and interconnects, as well as physical connectors (sockets, slots, and headers) into which other computer components may be inserted or attached.

Most motherboards include, at a minimum:

• sockets (or slots) in which one or more microprocessors (CPUs) are installed^[4]
• slots into which the system's main memory is installed (typically in the form of DIMM modules containing DRAM chips)
• a chipset which forms an interface between the CPU's front-side bus, main memory, and peripheral buses
• non-volatile memory chips (usually Flash ROM in modern motherboards) containing the system's firmware or BIOS
• a clock generator which produces the system clock signal to synchronize the various components
• slots for expansion cards (these interface to the system via the buses supported by the chipset)
• power connectors and circuits, which receive electrical power from the computer power supply and distribute it to the CPU, chipset, main memory, and expansion cards.^[5]

The Octek Jaguar V motherboard from 1993.^[6] This board has 6 ISA slots but few onboard peripherals, as evidenced by the lack of external connectors.

Additionally, nearly all motherboards include logic and connectors to support commonly-used input devices, such as PS/2 connectors for a mouse and keyboard. Early personal computers such as the Apple II or IBM PC included only this minimal peripheral support on the motherboard. Additional peripherals such as disk controllers and serial ports were provided as expansion cards.

Given the high thermal design power of high-speed computer CPUs and components, modern motherboards nearly always include heatsinks and mounting points for fans to dissipate excess heat.

[edit] Integrated peripherals

With the steadily declining costs and size of integrated circuits, it is now possible to include support for many peripherals on the motherboard. By combining many functions on one PCB, the physical size and total cost of the system may be reduced; highly-integrated motherboards are thus especially popular in small form factor and budget computers.

For example, the ECS RS485M-M,^[7] a typical modern budget motherboard for computers based on AMD processors, has on-board support for a very large range of peripherals:

• disk controllers for a floppy disk drive, up to 2 PATA drives, and up to 6 SATA drives (including RAID 0/1 support)
• integrated ATI Radeon graphics controller supporting 2D and 3D graphics, with VGA and TV output
• integrated sound card supporting 8-channel (7.1) audio and S/PDIF output
• fast Ethernet network controller for 10/100 Mbit networking
• USB 2.0 controller supporting up to 12 USB ports
• IrDA controller for infrared data communication (e.g. with an IrDA enabled Cellular Phone or Printer)
• temperature, voltage, and fan-speed sensors that allow software to monitor the health of computer components

Expansion cards to support all of these functions would have cost hundreds of dollars even a decade ago, however as of April 2007 such highly-integrated motherboards are available for as little as $30 in the USA.

[edit] Temperature and reliability

Motherboards are generally air cooled with heat sinks often mounted on larger chips, such as the northbridge, in modern motherboards. Passive cooling was sufficient for many desktop computer CPUs until the late 1990s; since then, most have required CPU fans mounted on their heatsinks, due to rising clock speeds and power consumption. Most motherboards have connectors for additional case fans as well. Newer motherboards have integrated temperature sensors to detect motherboard and CPU temperatures, and controllable fan connectors which the BIOS or operating system can use to regulate fan speed.

Some small form factor computers and home theater PCs designed for quiet and energy-efficient operation boast fan-less designs. This typically requires the use of a low-power CPU, as well as careful layout of the motherboard and other components to allow for heat sink placement.

A 2003 study^[8] found that some spurious computer crashes and general reliability issues, ranging from screen image distortions to I/O read/write errors, can surprisingly be attributed not to software or peripheral hardware but to aging capacitors on PC motherboards.

For more information on premature capacitor failure on PC motherboards, see capacitor plague.

Motherboards use electrolytic capacitors for voltage regulation. These capacitors age at a temperature-dependent rate, as their water based electrolytes slowly evaporate. This can lead to loss of capacitance and subsequent motherboard malfunctions due to voltage instabilities. While most capacitors are rated for 2000 hours of operation at 105 °C,^[9] their expected design life roughly doubles for every 10 °C below this. At 45 °C a lifetime of 15 years can be expected. This appears reasonable for a computer motherboard, however many manufacturers have delivered substandard capacitors, which significantly reduce this life expectancy. Inadequate case cooling and elevated temperatures easily exacerbate this problem. It is possible, but tedious and time-consuming, to find and replace broken capacitors on PC motherboards; it is often cheaper to buy a new motherboard than to pay for such a repair.

[edit] History

Prior to the advent of the Apple II in 1977, a computer was usually built in a case or mainframe with components connected by a backplane consisting of a set of slots themselves connected with wires. The CPU, memory and I/O peripherals were housed on individual PCBs or cards which plugged into the backplane.

With the arrival of the microprocessor, it became more cost-effective to place the backplane connectors, processor and glue logic onto a single "mother" board, with video, memory and I/O functions on "child" cards — hence the terms "motherboard" and daughterboard. The Apple II computer featured a motherboard with 8 expansion slots.

During the late 1980s and 1990s, it became economical to move an increasing number of peripheral functions onto the motherboard (see above). In the late 1980s, motherboards began to include single ICs (called Super I/O chips) capable of supporting a set of low-speed peripherals: keyboard, mouse, floppy disk drive, serial ports, and parallel ports. As of the early 2000s, many motherboards support a full range of audio, video, storage, and networking functions without the need for any expansion cards at all; higher-end systems for 3D gaming and computer graphics typically retain only the graphics card as a separate component.

The early pioneers of motherboard manufacturing were Micronics, Mylex, AMI, DTK, Hauppauge, Orchid Technology, Elitegroup, DFI, and a number of Taiwan-based manufacturers.

It can be argued that the motherboard industry was born by IBM in 1981 with the release their entry level 5150 Personal Computer (IBM PC) which was based on a motherboard. The motherboard provided an Intel 4.77MHz 8088 with 16K bytes of on-board memory, expandable to 640K through the use of plug-in memory boards, eight 8-bit ISA expansion connectors, cassette tape port and keyboard port. All other I/O such as the interface for 160K 5-1/4" floppy drives, serial and parallel ports were provided by plug-in boards. IBM approached Digital Research about using DR/DOS as an operating system but was rebuffed. IBM approached Microsoft and licensed PC-DOS. Microsoft released PC-DOS 1.1 in 1982 by retaining rights to the operating system allowing them to sell it to other manufacturers.
